CSE-847 with X9DRH-IF System Board 4U 36-Bay LFF

Silicon Mechanics co-brand Includes dual power supplies, dual heat sinks, no rails Key Features CPU - Dual Intel® E5-2600 (V2) Series (Socket R) processors; each processor supports two full-width Intel QuickPath Interconnect (QPI) links (with support of up to 8.0 GT/s per QPI link) Memory - Integrated memory controller supports up to 1TB of 240-pin Registered (RDIMM)/Load Reduced (LRDIMM)/Non-Volatile (NVDIMM) ECC or Unbuffered (UDIMM) ECC/Non-ECC DDR3 1866/1600/1333/1066/800 MHz memory in 16 slots (1866 MHz is not available on NVDIMMs.) Note 1: For the latest memory updates, please refer to our website at http://www.supermicro. com/products/motherboard. Note 2: NVDIMM memory support is available on the X9DRH-iF & X9DRH-iF-NV only. Chipset - Intel® C602 (PCH) Expansion - Three (3) PCI-E x8 slots (CPU1 Slots 1, 2, 3) • Three (3) PCI-E x8 slots (CPU 2 Slots 5, 6, 7) • One (1) PCI-E 3.0 x16 (CPU 2 Slot 4) Slots Graphics - Nuvoton BMC Video Controller (Matrix E200) Network - One Intel I350/X540 10-Gigabit Ethernet Dual-Channel Controller for LAN1/LAN2 ports (GLAN Ports for -7F/- iF/-iF-NV) - Nuvoton WPCM 450 Baseboard Controller (BMC) supports IPMI_LAN 2.0
